CARLO GAVAZZI VariFlex3 RVLF Series User Manual

Motor Controllers AC Variable Frequency Drives Type VariFlex
3
RVLF
Group 08 Drive & motor protection functions
No. Description Range
Factory
setting
Unit Note
08-12
PTC Detection Time Delay 1 ~ 300 60 Sec
08-13 PTC Protection Level 0.1 ~ 10.0 0.7 Sec
08-14 PTC Detection Level 0.1 ~ 10.0 0.3 V
08-15 PTC Warning Level 0.1 ~ 10.0 0.5 V
08-16 Fan Control Temperature 10.0 ~ 50.0 50 °C
08-17 Over Current Protection Level 0.0 ~ 60.0 0.0 A
08-18 Over Current Protection Time 0.0 ~ 1500.0 1.0 Sec
08-19 Motor Overload Protection Level
0: Motor Overload Protection Level 0
1: Motor Overload Protection Level 1
2: Motor Overload Protection Level 2
0
Group 09 Communication function setup
No. Description Range
Factory
setting
Unit Note
09-00
Assigned communication station
umber
1~32 1 - *2*3
09-01 RTU code /ASCII ode select
0: RTU code
1: ASCII code
0 - *2*3
09-02 Baud rate setting (bps)
0: 4800
1: 9600
2: 19200
3: 38400
2 bps *2*3
09-03 Stop bit selection
0: 1 Stop bit
1: 2 Stop bits
0 - *2*3
09-04 Parity selection
0: Without parity
1: With even parity
2: With odd parity
0 - *2*3
09-05 Data format selection 0: 8-Bits data 1: 7-Bits data 0 - *2*3
09-06
Communication time - out detection
time
0.0~25.5 0.0 s
09-07
Communication time-out operation
selection
0: Deceleration to stop
(00-15: deceleration time 1)
1: Coast to stop
2: Deceleration to stop
(00-17: deceleration time 2)
3: Continue operating
0 -
09-08 Error 6 verication time. 1~20 3
09-09 Drive transmit delay time (ms) 5~65 5 ms
09-10 BACmet Station 1~254 1 *2*3
54 Specications are subject to change without notice. Pictures are just an example. For special features and/or customization, please ask to our sales network. 13/12/2017
