Carlson Quarryman Pro - Quarryman Pro Specifications

Page | 53
10 Quarryman Pro Specifications
Laser module
Laser classification BS EN 60825-1:2014
(21 CFR 1040.10 and 1040.11 except for
deviations pursuant to Laser No. 50, dated 24
June 2007)
Class 2*
Infrared laser module
Type InGaAs laser diode
Wavelength (typ) 905 nm
Maximum energy per pulse 675 nJ
Beam divergence 2.25 × 0.15 mrads
Resolution 1 cm
Maximum range to a passive target** Up to 750 m
Minimum range 10 m
Lens aperture size and location 46 mm (location at front of module)
Visible laser module
Type InGaAsP laser diode
Wavelength (typ) 650 nm
Maximum power < 0.6 mW (continuous wave)
Lens aperture size and location 3 mm (location at front of module)
Angle
Encoder type Opto-electronic encoder
Encoder accuracy 0.02°
Encoder resolution 0.01°
Mechanical range Vertical −45° to +90°
Horizontal 0° to 360°
Mechanical motion Stepper-driven worm and wheel drives in both axes with
manual clutch override
Keyboard and display
Display 3.5 inch, sun-readable TFT
Resolution 320 × 240
Keyboard 17-button keypad
Data logging
Supplied logging media 8 GB USB drive
Compatibility USB 2.0 and 3.0
