Carrier TRANSICOLD Vector 8600MT - Control Box Fuse Layout

62-11648 50
Figure 1.3 Control Box
Fuse Purpose Amps/Volts
AC
F30/F31/F32 2nd Compartment (MT only) 12/600
F33/F34/F35 Battery Charger 5/600
F36/F37/F38 Fans (condenser and Evaporator) 12/600
F39/F40/F41 Heater Strips 12/600
F42/F43/F44 3rd Compartment (MT only) 12/600
