62-11648 22
11. Turning Compartments On/Off
Individual compartment control status and temperature display boxes are
configured left to right to match the compartments in the trailer, front to back.
The left display box shows the status of the first compartment (C1), the middle
display box shows the status of the second compartment (C2), and the right
display box shows the status of the third compartment (C3). In a two-
compartment configuration, the right display box is blank.
The default display screen uses a highlight box to allow control of individual
compartments. The highlight box will toggle between each of the
compartments that are currently ON. If only one compartment is ON, the
highlight box will remain on that compartment.
Compartment 1 Compartment 2 Compartment 3
Temp NA
OFF
Setpoint -10
Temp 28.1
Cool Mode
Setpoint 28
Temp 36.2
Cool Mode
Setpoint 36
START/STOP DIESEL
BOX
SETPOINT
STATUS OK
o
F
TEMP
OFF
-10
28.1 36.2
28
COOL COOL
36
