Table 5 -- Holiday Configuration (HOLDYXXS)
DESCRIPTION DISPLAY POINT
Start Month XX MONTH
Start Day XX DAY
Duration XXX DURATION
RANGE
1-12
1-31
0-365
DEFAULT
1
1
0
Table 6 -- Remote Attach Configuration (REMOTE)
DESCRIPTION
Remote Attach
ALL DEVICES
Remote Attach Enable
Remote Device
Bus Number
Element Number
Space Temp Variable
NON-3V ONLY:
Cool Setpoint
Table Name
Setpoint Name
Low Limit
High Limit
Heat Setpoint
Table Name
Setpoint Name
Low Limit
High Limit
Mode Calculation
Supply Temp Variable
Fan Statue Variable
*ASCII rangelimited to A-Z, 0-9,underscore, dash.
DISPLAY POINT RANGE DEFAULT
Disable/Enable
XXX
XXX
XXXXXXXX*
XXXXXXXX
XXXXXXXX
xxx.x dF
xxx.x dF
XXXXXXXX
XXXXXXXX
XXX.X
XXX.X
Disable/Enable
XXXXXXXX
XXXXXXXX
dF
dF
R ATTACH
BUSNO
ELENO
SPT_VAR
CSP_TAB
CSP_NAME
CSP LLIM
CSP HLIM
HSP TAB
HSP_NAME
HSP_LLIM
HSP HLIM
MOD-ECALC
SAT VAR
SFS-VAR
0-1
0-239
0-239
ASCII*
ASCII*
ASCII
-40-245
-40-245
ASCII*
ASCII
-40-245
-40-245
0-1
ASCII*
ASCII*
Disable
o
o
SPT
(blank)
(blank)
-4O
245
(blank)
(blank)
-4O
245
Disable
SAT
SFS
REMOTE DEVICE BUS NUMBER -- Use this decision to
configure the bus number of the remote device. Tile remote
device can be on any Carrier communicating network bus.
Remote Device
Bus Number: Allowable Entries 0 to 239
Default Value 0
ELEMENT NUMBER -- Use this decision to configure the
element number of the remote device. Element Number must
be non-zero and Remote Attach Enable must be set to Enable
for the remote attach function be used.
Element Number: Allowable Entries 0 to 239
Default Value 0
SPACE TEMP VARIABLE --Use this decision to supply
the mune of fileCarrier communicating network space temper-
ature variable to be written to by the System Pilot. Space
temperature will be written to the remote device once a minute
or whenever the value changes by 0.3 ° E
Space Temp
Variable: Allowable Entries Up to 8 characters - up-
per case letters, numbers,
-, or
Default Value SPT
SET PO[NT MODIFICATION (NON-3V ONLY) -- The
System Pilot can monitor and/or modify up to two set points in
the specified device from the Remote Attach Default Screen.
The set point(s) must be in a set point table. Tile two set points
do not have to be in the same set point table.
The System Pilot reads the set points once per minute grad
updates them upon user request from the Remote Attach
Default Screen.
Cool Set Point Table Name -- Use this decision to specify
the Table Nmne containing the Cool Set Point to be monitored
and/or updated by the System Pilot.
Cool Set Point
Table Name: Allowable Entries Up to 8 characters - up-
per case letters, numbers,
-, or
Default Value (blank)
Cool Set Point Name -- Use this decision to specify the point
name of the Cool Set Point to be monitored and/or updated by
the System Pilot.
Cool Set Point
Name:
Allowable Entries Up to S characters - up-
per case letters, numbers,
-, or
Default Value (blank)
Cool Set Point Low Limit -- Use this decision to specify the
lowest value that can be sent to the cool set point specified by
the Table Name and Set Point Name. If the value being sent is
below this limit, the System Pilot will clmnp the value to this
limit before sending it to the device.
This limit will not affect the set point display. The System
Pilot will mad the set point from the device and display it as
mad, even if outside the high and low limits. Also, this limit
will only apply if the set point units am degrees F or C.
If clamping the set point results in a value that is outside the
configuration limits mad from the device, the System Pilot will
display an error indication ("LIMIT") and will not write the set
point to the device.
Cool Set Point
Low Limit: Allowable Entries -40 to 245 F
Default Value -40 F
Cool Set Point High Limit -- Use this decision to specify the
highest value that can be sent to the cool set point specified by
the Table Name and Set Point Name. If the value being sent is
above this limit, the System Pilot will clmnp the value to this
limit before sending it to the device.
This limit will not affect the set point display. The System
Pilot will mad the set point fi'om the device and display it as
mad, even if outside the high and low limits. Also, this limit
will only apply if the set point units am degrees F or C.
If clamping file set point results in a value that is outside the
configuration limits mad from the device, the System Pilot will
display an enor indication ("LIMIT") and will not write the set
point to the device.
Cool Set Point
High Limit: Allowable Entries -40 to 245 F
Default Value 245 F
