Carrier 40GVM Series - CONNECTION DIAGRAM

13
CONNECTION DIAGRAM
G
G
Terminal Block
Conduit panel
Conduit
Outdoor unit
Covered conduit connection for size 18k only
L1 L2 GND L2 S L1 L2 S L1 GND
Ground Ground
208/230 Low V DC 208/230 208/230 Low V DC 208/230
Power and Control Signal to
Indoor Units
Two - Five Terminal Blocks
Power to Outdoor
Unit
Supply
208/230-1-60
Power
Power to
Indoor Unit
Control to
Indoor Unit
Power to
Indoor
Unit
Main
Control from
Outdoor Unit
Power from
Outdoor Unit
Outdoor Unit Terminal Blocks
38GVM-40GVM 18K - 42K Connection Diagram
This Series of Connections Will be Repeated for Each Indoor Unit (A to A - B to B etc.)
CONNECTING CABLE
OUTDOOR TO INDOOR
Unit "A"
Indoor Unit Terminal Block (1)
Unit "A"
Power from
Outdoor Unit
A12558
Fig. 11 – Field Wiring
