Carrier 40GVM Series User Manual

50
Steps
Procedure
8. Remove 4-way valve
6. Remove sound shield
7. Remove reactor
Carefully remove the sound shield from around
the compressor.
Sound Shield
Reclaim system refrigerant charge.
Cut all lines connected to 4-way valve;
disconnect solenoid coil wiring and remove
4-way valve from unit.
4-Way
Valve
Reactor
Remove screws holding the reactor to the
compressor partition; then remove the reactor.
