Carrier 40GVM Series User Manual

59
Steps Procedure
Grille
6. remove the grille
Cabinet
plate to remove guard grille.
4.Remove guard grille
Guard grille
5. Remove right side plate
Remove the screws connecting the right side plate
with the chassis, the valve support and the electric
box, and then remove the right side plate assy .
Remove the 4 screws connecting the grille and the
Cabinet, and then remove the grille.
Right side plate
