26
FUNCTION AND CONTROLS CONTINUED
When the is displayed, the louver will swing continuously
between positions 1 and 5 as shown below.
OFF
01 2 3 4
5678
A09634
If the “SWING”
button is pushed again,the louver will
move to position 1. If position 2 through 5 is desired, push the
button repeatedly until the desired position (2 through 5)
is displayed on remote control.
Setting the louvers to move continuously:
This setting allows the louvers to move continuously between
either positions 1 through 5, or between positions 6, 7, and 8.
Push the
button once to have louvers swinging between
positions 1 and 5. If position 6, 7, or 8 is desired, push the
button repeatedly until the desired position is displayed on the
remote.
NOTE: Always use the remote control to adjust the horizontal
louver position otherwise, abnormal operation may occur. If
this occurs, turn the unit off and then on again.
Sometimes, in the heating mode, when the
”SWING”
button is pushed, the louvers will not start moving right away.
This is due to the fact that the fan will not start running until
the coil temperature is warm enough to prevent discomfort to
theuserbyblowingcoldair.
Sleep
Mode
This mode is used to conserve energy and can be used when the
unit is in the COOL, HEAT or DRY mode only.
For Cooling Mode:
S Push the SLEEP button. The SLEEP display will appear
on the remote control.
OPER
º
F
º
C
HOUR
ON/OFF
:
A09644
S After 1 hour the set point will be raised by 1.8_F(1_C).
S After another hour, the set point will be raised by another
1.8_F(1_C)andthefanwillruninlowspeed.
S The SLEEP mode will be cancelled when the SLEEP
button is pushed again.
For Heating Mode:
S Same as cooling mode but set points will be lowered by
1.8_F(1_C) and the HEAT icon will disappear from the
display panel.
Timer
Function
TIMER ON (to start the unit) and TIMER OFF (to stop the unit)
can be used separately or together. The clock on the remote control
must be set before using this function.
Timer ON
only
º
F
º
C
HOUR
:
OPER
Only ON
is displayed.
ON
A09639
This function will allow the unit to start automatically at the set
time. The TIMER ON can be set while the unit is on or off.
To set the TIMER ON function, perform the following:
1. Push the “TIMER ON” button once.
2. The clock indicator
and time will not be displayed on
the remote control. The default “TIMER ON” time (first
time function is used) or the last time setting will be
displayed and “ON” will flash.
3. Push the “--” or “+” within 5 seconds until the desired on
time is displayed.
NOTE: Pressing the “--” or “+” will decrease or increase the
time in 1 minute increments.
Pressing the “--” or “+” continuously will decrease or increase
the time in 10 minute increments.
4. Push the “TIMER ON” again. The “ON” icon will stop
blinking and the time at which the unit will start is set. The
clock indicator
and the time will be displayed again.
The “TIMER ON” time will be stored in memory indefinitely until
it is cancelled by the user by pushing the “TIMER ON” button or
the remote control batteries are replaced.
If the unit is running and the “TIMER ON” set time is reached, the
unit will continue operating normally.
NOTE: When the unit is shut off by the user using the
“ON/OFF” button, and if the “TIMER ON” is set, the
following will be displayed on the remote control.
-- Set Point
-- T i m e
-- Clock indicator
next to time indicates TIMER ON is set.
On the display panel, the operation light will turn red.
When the “TIMER ON” set time is reached, the display on the
remote does not change, but the unit will run as indicated by the
operation light on the front cover turning green. To get display on
the remote, push the “ON/OFF” button once.
Timer OFF
only
This function will allow the unit to stop automatically at the set
time. The timer can be set while the unit is on or while it is off.
To set the “TIMER OFF” function, perform the following:
1. Push the “TIMER OFF” button once.
2. The clock indicator
and time will not be displayed.
“OFF” will be flashing.
3. Push the “--” or “+” button within 5 seconds until the
desired ON time is displayed.
NOTE: Pressing the “ --” or “+” will decrease or increase the
time in 1 minute increments.
Pressing the “--” or “+” continuously, will decrease or increase
the time in 10 minute increments.
4. Push the “TIMER OFF” button again, the “OFF” icon will
stop blinking and the time at which the unit will turn off is
set. The clock indicator
and the time will be displayed
again.
