DLCLRC: Installation Instructions
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
4
DIMENSIONS
Table 3 — Dimensions
Fig. 4 —Size 36K
UNIT SIZE 36K 48K 58K
Height in (mm) 31.89 (810) 52.48 (1333) 52.48 (1333)
Width in (mm) 37.24 (946) 37.48 (952) 37.48 (952)
Depth in (mm) 16.14 (410) 16.34 (415) 16.34 (415)
Operating Weight lbs (kg) 155.42 (70.5) 219.14 (99.4) 217.15 (98.5)
Shipping Weight lbs (kg) 166.23 (75.4) 249.12 (113) 248.24 (112.6)
Shipping Height in (mm) 34.45 (885) 34.45 (885) 34.45 (885)
Shipping Width in (mm) 42.91 (1090) 42.91 (1090) 42.91 (1090)
Shipping Depth in (mm) 19.69 (500) 19.69 (500) 19.69 (500)
