Point name Status Default Unit Displayed text* Description
6 I_cr_no 0 to 20 0 mA Current No Reset Value Current no reset value
7 I_cr_fu 0 to 20 0 mA Current Full Reset Value Current full reset value
8
cr_deg -16.7 to 16.7
-30.0 to 30.0
0
0
^C
^F
Cooling Reset Deg. Value Cooling reset deg. value
9 HEATING RESET Heating reset parameters
10 oathr_no -10.0 to 51.7
14.0 to 125.0
-10.0
14.0
°C
°F
OAT No Reset Value OAT no reset value
11 oathr_fu -10.0 to 51.7
14.0 to 125.0
-10.0
14.0
°C
°F
OAT Full Reset Value OAT full reset value
12 dt_hr_no 0 to 13.9
0 to 25.0
0
0
^C
^F
Delta T No Reset Value Delta T no reset value
13 dt_hr_fu 0 to 13.9
0 to 25.0
0
0
^C
^F
Delta T Full Reset Value Delta T full reset value
14 I_hr_no 0 to 20 0
mA Current No Reset Value Current no reset value
15 I_hr_fu 0 to 20 0
mA Current Full Reset Value Current full reset value
16 hr_deg -16.7 to 16.7
-30.0 to 30.0
0
0
^C
^F
Heating Reset Deg. Value Heating reset deg. value
*Depends on the selected language (English by default).
User Conguration Menu – USERCONF
Point name Status Default Unit Displayed text* Description
1 use_pass - 11 - User Password The password required to access User
Conguration menu
2 alert_r no/yes no -
Alarm Relay for Alerts?
Alarm relay status. Alarm output relay is used for
"alarm" + "alert"
*Depends on the selected language (English by default).
Schedule Menu – SCHEDULE
Point name Status Default Unit Displayed text* Description
1 OCCPC01S - - -
OCCPC01S - Schedule Menu Unit on/o time schedule
2 OCCPC02S - - - OCCPC02S - Schedule Menu Unit setpoint selection time schedule
*Depends on the selected language (English by default).
Holiday Menu – HOLIDAY
Point name Status Default Unit Displayed text* Description
1 HOL_MON 0-12 0 -
Holiday Start Month Holiday start month
2 HOL_DAY 0-31 0 - Start Day Holiday start day
3 HOL_LEN 0-99 0 - Duration (days) Holiday duration (days)
*Depends on the selected language (English by default).
Broadcast Menu – BROADCAST (BROCASTS)
Point name Status Default Unit Displayed text* Description
1 Ccnbroad 0 to 2 2 Activate Not applicable
2 OAT Broadcast
3 oatbusnm 0 to 239 0 Bus Bus number of the unit with the outdoor
temperature sensor
4 oatlocad 0 to 239 0 Element Element number of the unit with outdoor
temperature
5 dayl_sel disable/enable disable Daylight Savings Select Summer/winter time activation (Daylight
saving selection)
Daylight Savings Select – Summer time (entering)
6 1 to 12 3 Month Month
7 1 to 7 7 Day of Week (1=Monday) Day of the week (1 = Monday)
8 1 to 5 5 Week Number of Month Week of the month

9 Stopmon 1 to 12 10 Month Month
10 Stopdow 1 to 7 7 Day of Week (1=Monday) Day of the week (1 = Monday)
11 Stopwom 1 to 5 5 Week Number of Month Week of the month
*Depends on the selected language (English by default).
