226
ITEM EXPANSION RANGE DEFAULT ENTRY
D.LV.T COOL/HEAT SETPT. OFFSETS
L.H.ON Dmd Level Lo Heat On –1 to 2 ^F 1.5
H.H.ON Dmd Level(+) Hi Heat On 0.5 to 20.0 ^F 0.5
L.H.OF Dmd Level(-) Lo Heat Off 0.5 to 2 ^F 1
L.C.ON Dmd Level Lo Cool On –1 to 2 ^F 1.5
H.C.ON Dmd Level(+) Hi Cool On 0.5 to 20.0 ^F 0.5
L.C.OF Dmd Level(-) Lo Cool Off 0.5 to 2 ^F 1
C.T.LV Cool Trend Demand Level 0.1 to 5 ^F 0.1
H.T.LV Heat Trend Demand Level 0.1 to 5 ^F 0.1
C.T.TM Cool Trend Time 30 to 600 sec 120
H.T.TM Heat Trend Time 30 to 600 sec 120
DMD.L DEMAND LIMIT CONFIG.
DM.L.S Demand Limit Select 0 to 3 (multi-text strings) 0
D.L.20 Demand Limit at 20 ma 0 to 100 % 100
SH.NM Loadshed Group Number 0 to 99 0
SH.DL Loadshed Demand Delta 0 to 60 % 0
SH.TM Maximum Loadshed Time 0 to 120 min 60
D.L.S1 Demand Limit Sw.1 Setpt. 0 to 100 % 80
D.L.S2 Demand Limit Sw.2 Setpt. 0 to 100 % 50
IAQ INDOOR AIR QUALITY CFG.
DCV.C DCV ECONOMIZER SETPOINTS
EC.MN Economizer Min.Position 0 to 100 % 5
IAQ.M IAQ Demand Vent Min.Pos. 0 to 100 % 0
AQ.CF AIR QUALITY CONFIGS
IQ.A.C IAQ Analog Sensor Config 0 to 4 (multi-text strings) 0
IQ.A.F IAQ 4-20 ma Fan Config 0 to 2 (multi-text strings) 0
IQ.I.C IAQ Discrete Input Config 0 to 2 (multi-text strings) 0
IQ.I.F IAQ Disc.In. Fan Config 0 to 2 (multi-text strings) 0
OQ.A.C OAQ 4-20ma Sensor Config 0 to 2 (multi-text strings) 0
AQ.SP AIR QUALITY SETPOINTS
IQ.O.P IAQ Econ Override Pos. 0 to 100 % 100
DAQ.L Diff.Air Quality LoLimit 0 to 1000 100
DAQ.H Diff.Air Quality HiLimit 100 to 2000 700
D.F.OF DAQ PPM Fan Off Setpoint 0 to 2000 200
D.F.ON DAQ PPM Fan On Setpoint 0 to 2000 400
IAQ.R Diff. AQ Responsiveness –5 to 5 0
OAQ.L OAQ Lockout Value 0 to 2000 0
OAQ.U User Determined OAQ 0 to 5000 400
AQ.S.R AIR QUALITY SENSOR RANGE
IQ.R.L IAQ Low Reference 0 to 5000 0
IQ.R.H IAQ High Reference 0 to 5000 2000
OQ.R.L OAQ Low Reference 0 to 5000 0
OQ.R.H OAQ High Reference 0 to 5000 2000
IAQ.P IAQ PRE-OCCUPIED PURGE
IQ.PG IAQ Purge Yes/No No
IQ.P.T IAQ Purge Duration 5 to 60 min 15
IQ.P.L IAQ Purge LoTemp Min Pos 0 to 100 % 10
IQ.P.H IAQ Purge HiTemp Min Pos 0 to 100 % 35
IQ.L.O
IAQ Purge OAT Lockout 35-70 dF 50
DEHU DEHUMIDIFICATION CONFIG.
D.SEL Dehumidification Config 0 to 3(multi-text strings) 0
D.SEN Dehumidification Sensor 1 to 2(multi-text strings) 1
D.EC.D Econ disable in DH mode? Yes/No Yes
D.V.CF Vent Reheat Setpt Select 0 to 1(multi-text strings) 0
D.V.RA Vent Reheat RAT offset 0 to 8 ^F 0
D.V.HT Vent Reheat Setpoint 55 to 95 dF 70
D.C.SP Dehumidify Cool Setpoint 40 to 55 dF 45
D.RH.S Dehumidify RH Setpoint 10 to 90 % 55
HZ.RT Humidimizer Adjust Rate 5 to 120 30
DH.DB Dehumidify RH Deadband 1 to 30
DH.TG Dehum Discrete Timeguard 10 to 90
HZ.PG Humidimizer Prop. Gain 0 to 10 0.8
HZ.OR Enable HMZR ST Oil Ret Disable/Enable Enable
CCN CCN CONFIGURATION
CCNA CCN Address 1 to 239 1
CCNB CCN Bus Number 0 to 239 0
BAUD CCN Baud Rate 1 to 5 (multi-text strings) 3
