GB - 11
Zone Manager
ENGLISH
• Use either the "up" or "down" button to change the current
number of degrees to setback. Allowable selections are 5-32
degrees.
NOTE:
The scale of the temperature is dependent up on the currently
configured scale. If the configuration item "1-" is set to "F" and
configuration item "4-" has a value of 16, then an Auto Mode
Setback Deadband of 16°F will be used. If the configuration
item "1-" is set to "C" and configuration item "4-" has a value of
16, then an Auto Mode Setback Deadband of 16°C will be used.
• To end configuration, either depress the "END PROGRAM" button
or do not push any buttons for 20 seconds.
5- NUMBER OF ZONES INSTALLED
This adjustment controls the number of zones on the system.
Factory default is 1 zone.
To adjust when in configuration mode:
• Press the "up" or "down" button until "5-" is displayed.
• Depress the "
SET TIME/TEMP" button to change the current
selection (current selection will now blink).
• Use either the "up" or "down" button to change the number of
zones installed, allowable selection are 1- 8 zones.
• To end configuration, either depress the "
END PROGRAM" button
or do not push any buttons for 20 seconds.
up
down
up
down
up
down
Configuration
