CAS CI-150A - Printer Test (TEST 5)

16
TEST 5
FUNCTION : Printer test(PRINTER)
KEY DISPLAY DESCRIPTION
SET key : next menu
No error in printer.
Do this test after connection serial printer.
TEST 6 (OPTION)
FUNCTION : A-OUT test
KEY DISPLAY DESCRIPTION
▲ Key : Value change
ZERO key : Cancel
SET key : next menu
25 P
The output level of Aout is raised by 25%
each time the
▲ key is pushed.
TEST 7 (OPTION)
FUNCTION : External Input / Output test
KEY DISPLAY DESCRIPTION
▲ Key : Value change
ZERO key : Cancel
SET key : next menu
I - X O - X
----------
I - 2 O – 4
Displayed in the external input section
when there is an external input.
Push ▲ key to execute weighing
external output
input : 2, output : 4
TEST 8 (OPTION)
FUNCTION : RTC test
KEY DISPLAY DESCRIPTION
SET key : next menu
SEC XX
XX : Displaying the progress of seconds
(SEC)
