TECHNICAL SPECIFICATION
Analog Part & A/D Conversion
Load cell excitation
voltage
DC 5 V
Zero adjust range
0.05 mV∼5 mV
0.5 uV/D
Input sensitivity
2 uV/D (CE)
Nonlinearity 0.01 % F.S.
A/D internal resolution 1/1,000,000
A/D external resolution 1/30,000(Max.)
A/D conversion speed 320 times/sec
Digital Part
Span calibration
Full Digital Calibration
(Single pass automatic span calibration)
Input noise below ±0.3μVpp
Input impedance over 10MΩ
Display 7 Segment(6 digit)
Maximum capacity 999999
Division
×2, ×5, ×10, ×20, ×50
Display below zero "-" minus signal
Permitted limit tare Full capacity
Key Description
"STABLE" ■LAMP
Weight is stable
"TARE" ■LAMP
Tare is used
"NET" ■LAMP
ON(NET weight), OFF(GROSS weight)
"HOLD" ■LAMP
Hold in Weight
"ZERO" ■LAMP
"0" kg
