CAS CI-150A - Analogue Output Settings

38
5. Analogue Output Setting (Option)
Menu-AOUT.01: A-out activation range setting
Function Set A-Out range
Display Part Meaning
AOBI. 0
Unipolar(operating in +weight)
Set Range
(0, 1)
AOBI. 1 Bipolar(operating in ±weight)
Menu-AOUT.02: V-out range setting
Function V-out range
Display Part Meaning
VRAN. 0 V-out is closed
VRAN. 1 0V ~ 5 V
VRAN. 2
0V ~ 10 V
VRAN. 3 ±5 V
Set Range
(0~4)
VRAN. 4 ±10 V
Note 1. Simultaneous output is not used. Therefore the V-out output range settings are applied with priority
during setting.
Note 2. When only using I-out, the V-out output range must be set to 0.
Menu-AOUT.03: I-out range setting
Function I-out range
Display Part Meaning
IRAN 0 I-out is closed
IRAN. 1 4 mA ~ 20 mA
IRAN. 2 0 mA ~ 20 mA
Set Range
(0 ~ 3)
IRAN. 3
0 mA ~ 24 mA
Menu-AOUT.04: Dual output(V-out & I-out)
Function Dual output(V-out & I-out)
Display Part Meaning
DUON. 0 Dual output disabled
Set Range
(0, 1)
DUON. 1
Dual output enabled
Menu-AOUT.05: Minimum weight of A-out
Function Minimum Output Weight Value upon Using Analog Out option
Display Part Meaning
Set Range
(0 ~ Max weight)
1000
2000
Initial value : 0
Minimum output at 1000 kg
Minimum output at 2000 kg
