6. Relay Setting (Option)
Menu-EXIO.01: Set Relay mode
Function Set Relay mode
Display Part Meaning
EXMD. 0
Limit Mode
EXMD. 1 Limit type Checker Mode
EXMD. 2 Checker Mode
EXMD. 3 Programmable Mode
Set Range
(0 ~ 4)
EXMD. 4 Packer Mode
※ Set the SP(Set Point) in the SET MODE
※ W = Weight
<Limit Mode>
Note.
1. Set value input requirement: SP2 > SP1
2. Relay Output
Step 1 : W ≥ SP1 ON
Step 2 : W ≥ SP2 ON
Finish : W ≥ SP2 & Stable ON
Near zero : Set value ≥ 0 range output
To Next Page
