CAS CI-150A - Page 45

46
Menu-EXIO.02: Set Ext Input 1
Function Set Ext Input 1
Display Part Meaning
EIN1. 00
External In1 is zero key
EIN1. 01 External In1 is tare/tareless key
EIN1. 02 External In1 is print key
EIN1. 03 External In1 is hold key
EIN1. 04 External In1 is hold clear key
Set Range
(0~5)
EIN1. 05 External In1 is start key
Menu-EXIO.03: Set Ext Input 2
Function Set Ext Input 2
Display Part Meaning
EIN2. 00 External In2 is zero key
EIN2. 01
External In2 is tare/tareless key
EIN2. 02 External In2 is print key
EIN2. 03 External In2 is hold key
EIN2. 04 External In2 is hold clear key
Set Range
(0~5)
EIN2. 05 External In2 is start key
Menu-EXIO.04: Relay Reverse On/Off
Function Relay Reverse On/Off
Display Part Meaning
EREV. 00
Relay Reverse OFF
Set Range
(0, 1)
EREV. 01 Relay Reverse ON
Menu-EXIO.05: Set Start Delay Time for completed Relay
Function Set Start Delay Time for completed Relay
Display Part Meaning
Set Range
(0, 99)
ERST. 10
Delayed by 00 x 0.1 Sec
Menu-EXIO.04: Set Operating Duration Time for completed Relay
Function Set Operating Duration Time for completed Relay
Display Part Meaning
Set Range
(0, 99)
EROT. 10
Delayed by 00 x 0.1 Sec
