CONTROL PANEL OVERVIEW
Heating Activated Light
The green pilot light located beneath the label HEATING ACTIVATED illuminates whenever the
workspace oven heating elements are powered and warming the oven. The oven uses measured
pulses to achieve and maintain the temperature set point.
OTL Light
Marked OVER TEMPERATURE ACTIVATED, this light illuminates whenever the Over Temperature
Limit heating cutoff system is routing power away from the heating elements. The OTL cuts off
heating when it detects an air temperature of 356°F (180°C) in the oven chamber.
Humidity Display
The humidity display shows the current humidity inside the oven chamber as a relative percentage
accurate to 0.1%. The display range is 0.0 – 99%.
