4 - INSTRUMENTS/CONTROLS
30
5. ENGINE OIL PRESSURE INDICATOR - There
are two levels of warning if the engine oil
pressure should drop significantly below its
normal pressure.
First level: Will illuminate indicator on tower and
sound alarm on new display for 5 seconds and a
continuous audible alarm will be sounded on the
instrument tower.
Second level: Will illuminate indicator on tower
and a continuos audible alarm will be sounded
on the new display and the stop engine indicator
(17) will illuminate and the continuous audible
alarm will sound on the instrument tower.
Turn off the engine and check the oil level in the
crankcase. Add oil if necessary to bring it to the
proper level. Turn OFF engine, remove key.
Check coolant level, air filter and air screen. Start
the engine. If the indicator still illuminates and the
audible alarm sounds, DO NOT operate the
engine. See your dealer.
6. COOLANT LEVEL INDICATOR - The indicator
will illuminate and a continuous audible alarm will
be sounded when the coolant level in the radiator
is low. Stop the engine and check the coolant
level in the radiator. Pressing the “ALARM OFF”
touchswitch will cancel the audible alarm.
7. COOLANT TEMPERATURE INDICATOR -
First level: Indicator will illuminate and a
continuous audible alarms will sound when the
coolant temperature is 220
° F (104° C).
Second level: Indicator will illuminate and a
continuous audible alarms will sound and the
engine stop indicator will illuminate when the
coolant temperature reaches 235
° F (113° C.).
RH97H011
5
6
7
