Case CX300C - RIGHT-HAND SIDE CONTROLS; Right-hand control arm

3-CONTROLS/INSTRUMENTS
RIGHT-HANDSIDECONTROLS
Right-handcontrolarm
UZS15G-001B1
1.Ignitionswitch
Thisswitchhasfourpositions,“On”(contact),
“Start”(engineignition),“Off”(engineshut-down)
and“Acc”(accessorycurrentsupply).
NOTICE:Whentheignitionkeyisin“On”(contact)
position,iftheanti-theftprotectionhasbeenpro-
grammed,thenitwillbenecessarytoenterthecode.
Themessage"Password"willbedisplayed.(Refer
topage4-4).
NOTE:Thiskeyisalsousedtolockthecabdoor,
theenginehood,thefrontstoragecompartment,the
sidedoorsandthefueltankcap.
2.Engineaccelerationbuttonandworkingmodeselec-
tor
Thisbuttonenablesanincreaseorreductioninthe
enginespeed.
Thisbuttoniscoupledwiththethreeworkingmode
selector.
Mode“A”(automatic)whentheenergyoutputhas
priority.
Inthismode,thebalancebetweenthespeedand
energyoutputiscontrolledforeachmovementofthe
controls.
Mode“H”fordifcultexcavationworkoriftheload
increases,andmode“SP”whentheoutputhaspri-
ority.
Eachselectedmode(A,HorSP)isdisplayedonthe
screen.
NOTE:Toselectthe“SP”mode,operatetheindex-
ingpinwhilerotatingtheaccelerationbuttontothe
right.
NOTE:Ifthereisnochangeinenginespeed,press
andreleasetheengineautomaticidlespeedselector.
3.Engineidlespeedselector
Thiscontrolenablesautomaticengineidlewithout
operatingthethrottlebutton.
Toselectidlespeed,pressandreleasethecontrol
fortheengineautomaticallytogointoidlespeed;
the"Engineidling"iconwillappearonthemessage
screens.
Whenthecontrolispressedandreleasedoncemore
theenginewillreverttoitsoriginalspeedandtheicon
onthesystemsdisplaypanelwilldisappear.
4.Armangleadjustmentlever
Thisleverisusedtoadjustthecontrolarmtilttosuit
theoperator.
Pullthelevertotherightandholditinthisposition,
tiltthecontrolarmtotherequiredpositionandthen
releasethelever.
ATTENTION:Theadjustmentofthecontrolarm
mustbedonewiththeenginestopped.
5.Travelcautionalarmswitch
“Cont”positionthealarmsoundswhenthetravel
controlsareactuated.
“Autooff”position,whenthetravelcontrolareactu-
ated,thealarmsoundsfor10secondsandthenstop.
6.Optioncontrol(ifequipped)
7.Optioncontrol(ifequipped)
8.Cabradio
Tooperatethecabradio.(Refertopage3-59).
9.Optioncontrol(ifequipped)
10.Wiperswitch
Whentheswitchispressed,thewipermoves.
11.Radioauxiliaryinputport
3-57
