1-GENERALINFORMATION

Productidentication

CX300Chydrauliccrawlerexcavator

1JOA94-0031

Pinplates

Whenorderingparts,obtaininginformationorassistance,alwayssupplyyourCASECONSTRUCTIONDealerwith

thetypeandserialnumberofyourmachineoraccessories.

Writethefollowinginthespacesbelow:thetype,serialnumberandyearofmanufactureofyourmachine,accessories

andtheserialnumbersofthevarioushydraulicandmechanicalcomponents.

Machine

(1)Type/ModelandCategory:

(HydraulicExcavator)CX300C.

(2)Productidenticationnumber:

QC3CE6-003N2

1-5
