Case CX300C - Travel reduction gears

6-MAINTENANCE
Travelreductiongears
Servicespecications
Oillevelcheck:Every250hours
Oildrain:Every1000hours(aftertherst250hoursduringtherun-inperiod)
Oilcapacity(perreductiongear):9.1l(2.4USgal)
Typeofoil:(Refertopage6-5)
Level
1.Parkthemachineonat,horizontalground.
2.Movethemachinesothatplug(1)isinthelowest
possibleposition.
3.Stoptheengineandremovetheignitionkey.
4.Removetheplug(2)andchecktheoillevel.Thelevel
mustcomeuptothebottomedgeoftheport(2).If
necessary,addoilthroughthisorice(2)untilthelevel
comesuptothebottomedgeoftheorice.Remove
theplug(2)andchecktheoillevel.
5.Installplug(2).
6.RepeatSteps2to5fortheothertravelreductiongear.
7.Travelslowlywiththemachineandmakesurethere
arenoleaks.
MMYFQD-0071
Drainingandrelling
1.Parkthemachineonat,horizontalground.
2.Movethemachinesothatplug(1)isinthelowest
possibleposition.
3.Shutdowntheengineandremovetheignitionkey.
4.Placeareceptacleofsuitablecapacityunderthetravel
reductiongearandremovethetwoplugs(1)and(2).
5.Allowtheoiltodrain.
ATTENTION:Checktheconditionofthedrainedoil.If
itcontainsmetallingsorforeignmatter,consultyour
CASECONSTRUCTIONDealer.
6.Installtheplug(1),llwithoilthroughtheorice(2)
untiloilcomesuptothebottomedgeoforicethen
installplug(2).
7.RepeatSteps2to6fortheothertravelreductiongear.
8.Travelslowlywiththemachineandmakesurethere
arenoleaks.
MMYFQD-0072
6-49
