2-SAFETYINFORMATION

Radiator

Partnumber:KHP1326

Thisdecalwarnsthattheradiatormustneverbetouched

andthattheradiatorcapmustneverberemovedwhile

thecoolingsystemisstillhot.Waitforthesystemtocool

downbeforecarryingoutanyoperation.

4ZOD29-00234

Fanbelt

Partnumber:KHP1337

Thisdecalwarnsthatthefanandthefanbeltmustnever

betouchedwhiletheengineisrunning.Stoptheengine

beforeperforminganyoperation.

90C1625135

Intercooler

Partnumber:KHP18130

Thisdecalwarnstheoperatornottotouchthehightem-

peraturecooler.

SR7QPG-00436

Opentheenginehood

Partnumber:KTP1089

Openthiscoverwithakeyandtheenginehoodopens

whenpullalever.

NT2IGP-00337
