Case CX300C - Locking the travel pedal

3-CONTROLS/INSTRUMENTS
Footrest
GTQCYL-001C13
Lockingthetravelpedal
Whenthetravelpedalisnotused,itisnecessarytolock
thepedal.
Forlockingthepedal,engagethelockingpin(1)inthe
lockinghole(2).
SNKQ6K-003A14
Forusingthepedal,placethelockingpin(1)inthisposi-
tion.
SNKQ6K-00115
NOTE:Ifthelockingpin(1)isinposition(3),onlyforward
travelispossible.
SNKQ6K-002A16
3-13
