Casio EXILIM EX-Z150 - General Guide

120
Appendix
The numbers in parentheses indicate the pages where each item is explained.
. Camera
. Charger Unit
General Guide
1
Shutter button (page 17)
2
[ON/OFF] (Power)
(page 16)
3
Microphone
(pages 40, 69)
4
Lens
5
Front lamp
(pages 19, 53)
6
Flash (page 26)
7
Zoom controller
(pages 17, 39, 63)
8
[p] (PLAY) button
(pages 16, 20)
9
Back lamp
(pages 16, 17, 26)
bk
[0] (movie) button
(page 40)
bl
[r] (REC) button
(pages 16, 17)
bm
Strap hole (page 2)
bn
Connector cover
bo
USB/AV port
(pages 64, 73, 81, 90)
bp
[BS] button (page 44)
bq
[MENU] button
(page 47)
br
[SET] button (page 23)
bs
Control button
([8][2][4][6])
(page 23)
bt
Monitor screen
(pages 105, 121)
3
21
4
57 6
[ ]
[ ]
[ ]
[ ]
[
SET
]
9 bk
bm
bn
bl8
bpbqbrbs bobt
Front Back
ck
Speaker
cl
Tripod hole
Use this hole when attaching to a tripod.
cm
Battery/memory card slots (pages 11, 14, 115, 117)
cmclck
Bottom
2
1
3
1
[CHARGE] Lamp
2
+- Contacts
3
AC jack
