Casio EXILIM EX-Z800 User Manual

109
Printing
You can connect the camera directly to a printer that supports PictBridge and print
images without going through a computer.
. To set up the camera before connecting to a printer
1. Turn on the camera. Next, press [SET] and then display the REC menu
(page 63) or the PLAY menu (page 90).
2. On the “Set Up” tab, select “USB” and then press [6].
3. Use [8] and [2] to select “PTP (PictBridge)”, and then press [SET].
. Connecting the Camera to a Printer
Use the USB cable that
comes bundled with the
camera to connect the
camera to your printer’s USB
port.
• The camera does not draw
power over the USB cable.
Make sure the camera’s
battery is sufficiently
charged before
connecting.
• Make sure that you insert
the cable connector into
the USB/AV port until you
feel it click securely into
place. Failure to insert the
connector fully can result
in poor communication or
malfunction.
• Note that even while the
connector is fully inserted, you still will be able to see the
metal part of the connector as shown in the illustration.
• When connecting the USB cable to a USB port, make sure
you align the connector correctly with the port.
Connecting Directly to a PictBridge Compatible Printer
USB cable
USB port
USB/AV port
Making sure that the mark on the USB cable
connector is towards the lens side, connect the cable to
the camera.
Large connector
Small connector

Casio EXILIM EX-Z800 Specifications

General

Megapixel	14.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.3 \
Supported aspect ratios	3:2, 16:9
Maximum image resolution	4320 x 3240 pixels
Digital zoom	6 x
Optical zoom	4 x
Combined zoom	63.8 x
Focal length range	4.9 - 19.6 mm
Lens structure (elements/groups)	6/5
Interface	USB 2.0
Digital SLR	No
Aperture range (F-F)	3.2 - 8
Camera shutter speed	1/2 - 1/2000 s
Compatible operating systems	-
Focal length (35mm film equivalent)	27 - 108 mm
Normal focusing range	0.2 - ∞ m
Auto focusing (AF) modes	Multi Point Auto Focus, Single Auto Focus, Spot Auto Focus
Macro focusing range (tele)	0.08 - 0.5 m
Light metering	Centre-weighted
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200, Auto
Flash modes	Auto, Flash off, Manual, Red-eye reduction
Flash range (tele)	0.4 - 2.3 m
Flash range (wide)	0.25 - 4.2 m
Internal memory	14.5 MB
Compatible memory cards	SD, SDHC
Motion JPEG frame rate	20 fps
Video formats supported	AVI, M-JPEG
Maximum video resolution	1280 x 720 pixels
Display diagonal	2.7 \
Display resolution (numeric)	230400 pixels
USB version	2.0
Scene modes	Landscape
Photo effects	Black&White, Vivid
White balance	Auto, Daylight, Manual, Tungsten
Product color	Blue
Battery type	NP-80
Battery life (CIPA standard)	280 shots
Number of batteries supported	1
Camera shutter type	electronic, mechanical

Weight and Dimensions

Depth	19.5 mm
Width	91 mm
Height	52.3 mm
Weight	124 g
