Page #128 background imageLoading...
Page #128 background image
128
Using the Camera with a Computer
If you are running Mac OS X, you can manage snapshots using iPhoto, which comes
bundled with some Macintosh products. If you are running Mac OS 9, you will need to
use commercially available software.
You can use QuickTime, which comes bundled with your operating system, to play
back movies on a Macintosh. To play back a movie, first copy it to your Macintosh
and then double-click the movie file.
. Minimum Computer System Requirements for Movie Playback
The minimum system requirements described below are necessary to play back
movies recorded with this camera on a computer.
The above are recommended system environments. Configuring one of these
environments does not guarantee proper operation.
Certain settings and other installed software may interfere with proper playback of
movies.
. Movie Playback Precautions
Proper movie playback may not be possible on some Macintosh models. If you
experience problems, try the following.
Change the movie image quality setting to “STD”.
Upgrade to the latest version of QuickTime.
Shut down other applications that are running.
Even if proper playback is not possible on your Macintosh, you can use the AV cable
that comes bundled with the camera to connect to the video input terminal of a TV or
Macintosh and play back movies that way.
IMPORTANT!
Be sure to move the movie data to the hard disk of your Macintosh before trying to
play it. Proper movie playback may not be possible for data accessed over a
network, from a memory card, etc.
Transferring Images Automatically and Managing Them on
Your Macintosh
Playing a Movie
Operating System : Mac OS X 10.3.9 or higher
Required Software: QuickTime 7 or higher

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Casio EXILIM EX-Z800 and is the answer not in the manual?

Casio EXILIM EX-Z800 Specifications

General IconGeneral
Megapixel14.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Image sensor size1/2.3 \
Supported aspect ratios3:2, 16:9
Maximum image resolution4320 x 3240 pixels
Digital zoom6 x
Optical zoom4 x
Combined zoom63.8 x
Focal length range4.9 - 19.6 mm
Lens structure (elements/groups)6/5
InterfaceUSB 2.0
Digital SLRNo
Aperture range (F-F)3.2 - 8
Camera shutter speed1/2 - 1/2000 s
Compatible operating systems-
Focal length (35mm film equivalent)27 - 108 mm
Normal focusing range0.2 - ∞ m
Auto focusing (AF) modesMulti Point Auto Focus, Single Auto Focus, Spot Auto Focus
Macro focusing range (tele)0.08 - 0.5 m
Light meteringCentre-weighted
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200, Auto
Flash modesAuto, Flash off, Manual, Red-eye reduction
Flash range (tele)0.4 - 2.3 m
Flash range (wide)0.25 - 4.2 m
Internal memory14.5 MB
Compatible memory cardsSD, SDHC
Motion JPEG frame rate20 fps
Video formats supportedAVI, M-JPEG
Maximum video resolution1280 x 720 pixels
Display diagonal2.7 \
Display resolution (numeric)230400 pixels
USB version2.0
Scene modesLandscape
Photo effectsBlack&White, Vivid
White balanceAuto, Daylight, Manual, Tungsten
Product colorBlue
Battery typeNP-80
Battery life (CIPA standard)280 shots
Number of batteries supported1
Camera shutter typeelectronic, mechanical
Weight and Dimensions IconWeight and Dimensions
Depth19.5 mm
Width91 mm
Height52.3 mm
Weight124 g
