Casio QT-6000 Reference Manual

R-51
QT-6000 Reference Manual
Note:
• Set a “%GET” command, first, to use the number entered by the arrangement key later.
•When the “%GET” is programmed following constant number input, the constant
number is saved to the parameter save buffer.
•Numbers input using a “%PUT” command or by “([number])” are entered to the
number entry buffer in the same way as numbers input using the 10-key pad.
2) Key function specification
Any function key can be specified for an arrangement key function. :
[function code]:[record number] → Used for ordinary function keys
The numbers can be specified for zero suppression.
Note:
The arrangement key itself, cannot be programmed for in an arrangement program.
3) Mode setting
Any mode key can be specified for an arrangement key function. :
[function code]:[mode definition]→ Used for mode keys
Note:
121:01 :REG mode
121:02 :REF mode
121:03 :REG– mode
122:01 :X/Z mode:
122:02 : MGR mode:
122:03 :Collection/Consolidation mode:
122:04 :Auto-program mode:
122:05 :CF card:
123:01 :PGM1 mode:
123:02 :PGM2 mode:
123:03 :PGM3 mode:
123:04 :PGM4 mode:
123:05 :PGM5 mode:
123:06 :PGM6 mode:
4) Print control
There are two commands for controlling the printer:
PON :Output printout data.
POFF :Not output printout data.

Casio QT-6000 Specifications

General

Types of payment	Cash
Second display	Yes
Second display type	LED
Power source	AC
AC input voltage	120-240 V
Power consumption	1100 mA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	311 mm
Width	343 mm
Height	288 mm
Weight	5300 g
