R-137
QT-6600 Reference Manual
2.
Press the <CANCEL> key.
3.
Press the <YES> key to cancel the transaction.
REG
C
01 10-10-01 12:34 000001
1 PLU0001 •1.00
1 PLU0002 •2.00
3 PLU0003 •9.00
1
Cancel OK?
PLU0004 •4.00
6 •16.00
REG
C
01 10-10-01 12:34 000001
1 PLU0001 •1.00
1 PLU0002 •2.00
3 PLU0003 •9.00
1 PLU0004 •4.00
CANCEL •••••••••••••
CANCEL 0.00
Please sign on.
140
142
Table of Contents
Default Chapter
5
Table of Contents
5
1 Hardware Configuration
10
General Configuration
10
Hardware Diagram
11
Keyboard
12
Display
13
Cash Drawer
14
Input/Output Connectors
15
Optional Peripherals
16
System Configuration
17
2 Application Systems
23
General Description of Application System
23
File Concept
23
Linkage of Totalizers
24
Function Keys
25
Keyboard Layout
25
Mode Control
26
Operation Prompt and Error Messages
26
Printing Control System
26
General Description of Individual Function Keys
29
System Keys
29
Finalize Keys
30
Transaction Keys
30
Remote Printer Control
39
Remote Printer System Configuration
39
Remote Printer Control Setting
40
Remote Printer Output Control
41
Remote Printer Backup Processes
41
Check Tracking System
44
Shared Check Tracking System
44
Shared Check Tracking Requirement
45
Data Backup When the Master Goes down
45
Other Check Tracking System Control
46
The Timing to Clear Check Detail and Index File after Finalization
46
Store and Recall
46
Clerk Control Function
48
Clerk Interrupt
48
Clerk Detail Memory
49
Clerk Training
49
Manager Mode Control
49
Arrangement Key Function and Scheduler
51
QT-6600 Reference Manual
51
Arrangement Key Function
51
Arrangement Program Example
55
Scheduled Execution of Arrangement Key Function
55
Making Graphic Logo
56
About Graphic Logo
56
Making Graphic Logo Procedure
56
Hourly Item
57
Programming Necessary Files before Using Hourly Item Function
57
Time and Attendance
58
Corresponding Relations of the File
59
Clock-In Operation
62
Clock-Out Operation
65
Sign on Control
68
Sign on
68
Solution to Abnormality of Master Terminal
69
Solution to Abnormality of Satellite Terminal
69
Sign on Compulsory
69
IDC (Item Data Capture
70
Available Capturing Items
70
Set up the IDC Start / End
73
IDC (Item Data Capture
73
How to Memorize the Captured Items
74
IDC Data File Structure
75
IDC Data Type
81
Transferring IDC
82
Electronic Journal
83
Storing Electronic Journal
83
Issuing Electronic Journal Report
83
Displaying Electronic Journal and Producing Guest Receipts after Sales
83
Transferring Electronic Journal Memory
84
Simple Time and Attendance
85
Clock-In Operation
85
Clock-Out Operation
86
Worktime Display
86
Report
86
Magnetic Card Reading
87
3 Manager Operation
90
Machine Initialization
90
Init
90
Flag Clear
90
Init2
90
INIT Code
91
IPL (Initial Program Loading
91
Ipl
91
IPL Via CF Card or COM1 Port
91
System Configuration before IPL Operation
92
IPL Operation
92
IPL Via LAN Port
92
IPL (Initial Program Loading
92
Manager Function
93
System Connection Check
94
Remote on
95
Remote off
95
Busy Reset
96
Stock Maintenance
97
Drawer for Clerk
98
CHK# (Clerk Interrupt
98
Order ID Change
98
Order ID Change
99
Error Log Print
100
System Re-Configuration
101
Item Data Capture
102
Euro Change over
103
Clerk Window
104
Customer
105
Customer Busy Reset
106
Sound
106
Print Batch Maintenance File
107
Execute Batch Maintenance File
108
Re-Index the Scanning PLU File
109
FTP Client
110
Licence Code Entry
110
Maintenance Data
111
Printer Logo Send
112
Clerk Number
113
Operation Monitor
113
System Command Execution
114
X/Z Reporting
114
X/Z Collection / Consolidation
116
Remote Power Control
116
Data Communication System
117
Inline / Online Connectors
117
Hardware Interface
118
Inline / Online Functions
120
Collection / Consolidation System
121
X/Z Collection
123
X/Z Consolidation
125
QT-6600 Reference Manual
125
X/Z Collection / Consolidation
128
Auto-Programming Function
131
Auto-Programming Functions
131
Auto-Program Operation and CF Card Utilities
132
4 Registrations
138
Clerk Sign on / off Operation
138
Voiding the Last Registered Item (<VOID> Key Operation
139
Voiding the Previous Registered Item (<VOID> Key Operation
140
Cancelling of All Data Registered During the Transaction
140
Using the List Function
142
Using the Set Menu Function and Pulldown Group Function
143
Post Entry
146
Separate Check
147
Open Check
148
Split Payment (Dutch Account
148
Media Change
149
Eat-In / Takeout
150
Scanning PLU
150
Shift PLU
153
Printing Barcode on Receipts (UP-400 and
153
Round Repeat Function
154
MIX & Match / Coupon
155
Customer
156
Order Character Change
157
Item Search
157
Scan MIX & Match
158
Time Calculation
159
Additional PLU Character
160
5 Refund Mode Operation
161
Selecting REF or REG- Mode
162
6 Read and Reset Operations
163
The Procedures of Reading or Resetting
164
Report Sample
166
A-1. Function Key List
181
A-2-4. PLU File
189
A-2-4-1 PLU (Daily
189
A-2-4-2 PLU (Periodic/Consolidation
189
A-2-4-3 PLU 2Nd
189
A-2-5-1 Scanning PLU
191
File Format
192
A-2-5-5 Batch Maintenance
192
A-2-5-6 Multi EAN Link
192
A-2-5-7 Non PLU Table
192
NLU Table
192
Department File
193
Group (Periodic/Consolidation
193
Clerk File
195
A-2-8-2 Clerk Detail (Daily, Periodic / Consolidation
196
A-2-8-3 Clerk Detail Link
196
A-2-8-4 Clerk (I-Button) Key ID
196
Hourly Sales File
197
A-2-9-1 Hourly Sales (Daily, Periodic/Consolidation
197
A-2-10. Monthly Sales File
197
A-2-10-1 Monthly Sales (Daily, Periodic/Consolidation
197
A-2-11. Hourly Item File
198
A-2-11-1 Hourly Item
198
A-2-11-2 Hourly Item Link (Hourly Production Link
198
A-2-12. MIX and Match File
199
A-2-12-1 MIX and Match (Daily
199
A-2-12-2 MIX and Match (Periodic/Consolidation
199
A-2-13. IDC File
200
A-2-13-1 IDC File (1
200
A-2-13-2 IDC File (2
200
A-2-13-3 IDC File (3
200
A-2-13-4 IDC Link
200
A-2-14. Time & Attendance File
201
A-2-14-1 Hourly / Labor
201
A-2-14-2. Work Time File
201
A-2-14-6. Schedule File
203
A-2-14-7. Simple Time and Attendance File
203
A-2-14-8. Clock-Out Reason File
203
A-2-17. Grand Total File
205
A-2-17-1 Grand Total (Daily
205
A-2-17-2 Grand Total (Periodic/Consolidation
205
A-2-20. Special Character File
208
A-2-20-1 Special Character
208
A-2-21. Report Header File
208
A-2-20-1 Report Header
208
A-2-22. Tax Table File
208
A-2-19-1 Tax Table
208
A-2-23. Pulldown Group File
209
A-2-23-1 Pulldown Group
209
A-2-24. Set Menu Table File
209
A-2-24-1 Set Menu Table
209
A-2-25-1 Batch X/Z
210
A-2-32. Scheduler File
212
A-2-32-1 Scheduler
212
A-2-33. Order Character File
212
A-2-33-1 Order Character
212
A-2-34. Euro Program File
212
A-2-34-1 Euro Program File
212
A-2-35. Character Conversion for CF File
212
A-2-35-1 Character Conversion for CF File
212
A-2-39. Add on VMP File
214
A-2-39-1 Add on VMP File
214
A-2-40. Intelligent EJ File
214
A-2-40-1 Intelligent EJ File
214
A-2-41. Menu Title Character File
214
A-2-41-1 Menu Title Character File
214
A-2-42. Tare Table File
214
A-2-42-1 Tare Table File
214
A-2-43. Screen Logo File
215
A-2-43-1 Screen Logo File
215
A-2-45. Additional PLU Program File
215
A-2-45-1 Additional PLU Program File
215
A-2-46. External Device Serial Number File
215
A-2-46-1 External Device Serial Number File
215
A-2-44. Full Screen Check Window (1) ~ (3) File
215
A-2-44-1 Full Screen Check Window (1) ~ (3) File
215
A-2-48. Free Function List File
216
A-2-48-1 Free Function List File
216
A-2-47. Additional PLU Character File
216
A-2-47-1 Additional PLU Character File
216
A-3.Counter and Totalizer Calculation Method
223
A-4. Error Messages
228
A-4-1 Error Messages
228
A-4-2 Operation Prompt
231
A-4-3 System Error Code
232
Index
