Casio QT-6600 Reference Manual

R-39
QT-6600 Reference Manual
OrderOrder
Up to 12 QT-6600 terminals
CHK/M
CHK/BM
PRN (1) PRN (2)
LAN Printer RS-232C Printer
Order OrderOrder
PRN (1) PRN (2) PRN(3)
Up to 16 remote printers
Slip
inline
C
C
C
C
C
C
C
C
QT-6600 QT-6600
QT-6600
Print
buffer
1
Remote
Printer
23
2-3. Remote printer control
Up to eight printers for printing kitchen orders etc.
2-3-1. Remote printer system configuration
Please refer to page 17 for the system configuration.
The printing processing of the remote printer is performed as shown in the figure below.
1 A transaction is made at a terminal.
2 The terminal sends printing data to the terminal with remote printer.
3 The terminal with remote printer sends data to the remote printer.
QT-6600 QT-6600
QT-6600
Print
buffer
1
Remote
Printer
23
RS-232C printer
LAN printer
