Casio QW-5311 User Manual

QW-5311
– 10 –10 ––
6-3. REMOVING THE DIAL AND THE SOLAR CELL
1) Removetheallhands.
Note: Do not damage the DIAL when removing the hands.
Second hand
Hour hand
Minute hand
24-hour hand
Mode hand
2) RemovetheHOLDER5219-2.
 TheHOLDER5219-2issecuredtotheANALOGBLOCKwithfourhooks(2H,4H,8H,10H).
Hooks
HOLDER5219-2
3) RemovetheDIAL.
 TheDIALissecuredtotheSOLARCELLwiththeTAPE/ADHESIVEs(5H,7H).
 DetachtheDIALformtheSOLARCELL,insertingthethinbladeofakinfebetweenthem.
DIAL
DIAL (Reverse side)
9H3H
TAPE/ADHESIVEs
