QW-5311

– 11 –11 ––

4) RemovetheSOLARCELL.

 TheSOLARCELLissecuredtotheANALOGBLOCKwithTAPE/ADHESIVEs(center12H,cen-

ter6H).

 DetachtheSOLARCELLformtheANALOGBLOCK,insertingthethinbladeofakinfebetween

them.

SOLARCELL

TAPE/ADHESIVEs

ANALOG BLOCK

Note: If the DIAL and the SOLAR CELL are reused, they can be detached from the ANALOG

BLOCK together as a set.

6-4. REMOVING THE PCB ASS’Y

1) DisengagetwoSCREW/FLAT2730andfourhooks,andthenremovethecircuitsupporter5311.

Hooks

SCREW/FLAT2730

Circuit supporter 5311

2) WhenremovingthePCBass'y,donotmisplacethespring/coils.

PCB ass'y

SCREW/FLAT4329

SPRING/COIL5140-1

SPRING/COIL1840-1

SPRING/COIL5140-2
