Casio XJ-UT310WN User Manual

19
10. After you copy all of the files you want, perform one of the operations below to
unmount the “InternalMem” drive.
11. Disconnect the USB cable from the projector and the computer.
12. Turn the projector back on.
z This stops internal storage function operation and returns to normal projection.
z For information about how to project a file copied to projector internal memory, see “Starting
Projection of Files Located in Projector Internal Memory” (page 20).
Note
z The above is presented only as a typical example of the file copy operation on a computer.
The actual steps you will need to perform may differ slightly in accordance with your
computer’s operating system and setup.
z If “On” is selected for “Internal Storage Password” on the setting menu, a password input
dialog box will appear when you press the [ENTER] key in step 3 of the procedure above. If
this happens, enter the appropriate password and then press the [ENTER] key to advance to
step 4 of the procedure. For details, see “Password Protection” (page 62).
Windows:
Click the “Safely Remove Hardware” icon in the task tray (in the lower right corner of the screen).
On the menu that appears, select “USB Flash Drive”. Check to make sure that a “Safe To
Remove Hardware” message appears.
Mac OS:
Drag the “InternalMem” drive icon to the trash can icon. Check to make sure that the
“InternalMem” drive icon is no longer on the Mac desktop.

Casio XJ-UT310WN Specifications

General

Matrix size	0.65 \
Matrix type	3-panel (p-Si TFT active)
Number of colors	16.78 million colors
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Supported aspect ratios	16:9, 16:10
Contrast ratio (typical)	1800:1
Screen size compatibility	50 - 110 \
Projector native resolution	WXGA (1280x800)
Keystone correction, horizontal	-5 - 5 °
Focus	Manual
Offset	118 %
Throw ratio	0.28:1
Focal length range	- mm
Light source type	Laser/LED hybrid
Service life of light source	20000 h
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, PAL, PAL 60, PAL M, PAL N, SECAM
Microphone in	Yes
Audio (L/R) in	2
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Noise level	34 dB
Noise level (economic mode)	29 dB
RMS rated power	16 W
Placement	Desktop, Ceiling
Product type	Ultra short throw projector
Product color	Grey, White
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.4 W
Power consumption (typical)	230 W
Operating altitude	0 - 3000 m
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	332 mm
Width	414 mm
Height	152.4 mm
Weight	5500 g
Package depth	470 mm
Package width	594 mm
Package height	274 mm
Package weight	9620 g
