10
Remote Control
Installation
1.Place the remote control upside up. Screw the rear
cover open with the screwdriver.
2. Pull out the battery case carefully (do not break the
wires connected).
3. Put in the batteries with correct polarity.
4. Push in the battery case and screw the rear cover
close.
1. TR/UL
2. Audio Source Input Selector
3. Mute Button
4. Volume Control Selector
Selector
Effective Distance：about 6m
◆Don't drop the remote control. Keep the remote control dry.
◆
◆
◆
◆
Replace the batteries timely.
Don't mix new and old batteries together and use the
batteries with the same specification.
Take out the batteries if you don't use the remote control for
an extended period of time.
Batteries with high quality are recommended.
NOTE:
ON OFF
VOL U ME
MIN
MAX
SELECTOR
POWER
TR/ UL
VACUUM TU BE INTEGRATED AMPLI FIER CS-55A
PHON ES
PHON OCD
AUX
USB
