230 Series Auger Packer
28 OF 115
The CBE 230 is an automatic packer. The operator is required to put an empty bag on the filling spout
and press the Start push button after the empty bag is in place. The Start, Stop and E-Stop Push Button
enclosure is located on the front of the packer.
The bag is then filled and weighed automatically, and when equipped with powered bag chair, is
discharged automatically.
If for any reason it is desired to interrupt the filling operation in the middle of a cycle, a red Stop
pushbutton is provided located directly underneath the green Start push button.
Depending on the style controller being used, pressing the Stop once will pause the filling process and
pressing the Stop twice, will abort the fill process.
It is recommended that the following adjustments be made to the packer before any material is delivered
to the receiving hopper:
Make sure all personnel are clear of machine.
Pneumatic Control System
Open manual valve for incoming high-pressure air.
Adjust pressure regulator to 80 PSIG (with power off).
Electrical control system is on.
Voltage coming in matches the sticker on the outside of the box.
Should your packer be equipped with a VFD, please be aware that VFD’s are voltage specific; if voltages
do not match, it will burn the VFD out.
PNEUMATIC ADJUSTMENTS
MAIN LINE PRESSURE
A minimum of 80 PSI should be maintained on the filter regulator at all times during normal operation.
Air pressure can be adjusted by a large hand knob at the top of the regulator. There is also a ¼ turn
needle valve at the bottom of the regulator underneath the water trap bowl. This devise serves to
separate some of the water out of your supply air before allowing it to enter into the bag filler. DRY AIR
IS REQUIRED FOR PROPER OPERATION OF THIS EQUIPMENT. THIS REGULATOR WILL NOT
SEPARATE ALL WATER FROM YOUR AIR SUPPLY. Special care and consideration should be made to
ensure that the compressed air being delivered to the filler is clean and dry. Drain and clean weekly or
