230 Series Auger Packer
30 OF 115
MECHANICAL ADJUSTMENTS
AUGER
WARNING: SHUT OFF ELECTRICAL POWER AND LOCK OUT BEFORE NEXT OPERATION
CAN BE DONE SAFELY.
The auger should not rub on the fill spout at any time. If auger is found not to be centered in the fill spout
and it is rubbing the fill spout, proceed as follow:
Shut off electrical power to machine and lock out
Check which way the auger has to move to get the auger centered in fill spout
Go to the rear of the packer and do as follows:
Loosen motor and remove belts
Take two ¾” wrenches and loosen four ½” bolts
Move bearing to make correct adjustment to the auger in fill spout
When the auger is aligned, put the bearings back together
Re-install all belts
Re-tighten motor
Adjust the position of the filling tube cutoff assembly so that it is centered around the auger with equal
clearance on all sides.
