CBE 230 - Page 63

230 Series Auger Packer
63 OF 115
Fill Spout Assembly, 3” OD, Non-Influencing, QD Auger, refractory, MS
CBE 212-1300-Q7578 PARTS LIST
ITEM
QTY
DESCRIPTION
PART
NUMBER
1
1
3" OD Fill Spout Tip for Non Influencing
206-506
2
1
Seal Ring for 3" OD Non-Influencing
206-505
3
1
3" OD Outer Spout for Non-Influencing
206-503
4
1
3" OD Inner Spout for Non-Influencing, Tapered Spout
206-802
5
1
Auger
KP102215-2
Not shown
1
Non-Influencing Fill Spout Retaining Wire
EPS-2047
Not shown
1
Neoprene Seal
011619315
Not shown
1
Auger Mounting Shaft
212-201
Not shown
1
Quill Auger Spindle Washer
212-202
Not shown
1
Locking Bolt, Spindle Washer
202-106-BOLT
