“50A”CAR (B1) AND LEISURE (B2) BATTERY PROTECTION FUSES
ELECTRONIC TANK PROBE - it measures the content of the water tanks, visualization in “%”.
(only for PC200 )“ ”
TANK PROBE WITH SCREWS “SS/P” - signalization of full waste water tank
ENGINE ALTERNATOR - it recharges in parallel both the car and the leisure battery
CAR BATTERY “B1”
CONTROL PANEL - mains’ control, battery test, tank test, (PC100 and PC200) - temperature
test and clock function (only for PC200 ).“ ”
12V DISTRIBUTION BOX “DS-300” - main relais, battery parallel relais (12V - 70A), fridge
relais, pump relais, car battery recharging device, protection fuses.
BATTERY CHARGER - buffer-system battery charger.
4-RODS TANKPROBE - it measures the content of the water tank, 4-levels visualization.
(only for PC100 )
fresh
“ ”
LEISURE BATTERY “B2” - it gives power to all the users
230V CUT-OUT board - it powers and protects all the 230V users
IMPORTANT Maintenance interventions on the electric implant must be carried out by
specialized personnel. Before carrying out maintenances disconnect the battery and the
230V alimentation line.
:
Read with care the instructions of use and maintenance of the batteries.
Check periodically the level of the liquid of the battery (with acid); the GEL battery does not need any
maintenance but a countinuous recharging.
In case of a longer stop, the services battery has to be disconnected or recharged regularly.
The battery charger must be installed in a dry and ventilated place.
Check the correct tightening of the connection binding screw and brush off the oxyde.
The installation of this device must be carried out by specialized technicians.
In case of battery charger’s misuse, the guarantee falls off and the manufacturer declines all
responsibility for damages to people and things.
BATTERY CHARGER
Do not carry out any maintenance when the battery charger is connected to the 230V power supply
net. Do not cover air intakes and assure an appropriate ventilation.
Before disconnecting the battery charger from 230V power supply, turn the security switch off.
If the leisure battery is removed, isolate the positive pole (in order to avoid short-circuits during an
accidental car engine starting).
TANK PROBES
Never let water in the tanks for long time, in order to avoid foulings, especially in the waste water
tank.
230V CUT-OUT BOX
The acid kept in the batteries is poisoning and corrosive. Avoid any contact with skin and eyes.
If the battery is completely discharged it needs recharging for almost 10 hours. If discharged for
more than 8 weeks it may be damaged.
BATTERIES
In order to avoid damages to the box, check the correct tightening of the connections.
In order to cut power to the whole 230V system, please take care that the 230V main switch must be
on the “0” (OFF) position.
Before taking away the cover, check that the 230V socket is disconnected.
Connect and disconnect the external 230V net only when the main switch is off.
Replace the fuses after finding out the real cause of the damage only.
When the fuses are replaced respect the value of the amperage established.
FUSES
In case of automatic switch break, find the damage before giving power again to the electrical
system.
GB
11
