CD Automation CD3000 E-3PH - Order Code Structure

CD Automation srl CD3000E-3PH from 25A to 500A User’s Manual
13
5.2 Order Code
Model 1 2 3 4 5 6 7 8 9 10 11 12 13
CD3000E-3PH
1 Max Current of CD3000E
25A 45A 100A 150A 300A 400A 500A
35A 75A 125A 225A 350A 450A 600A
The Max Current must be equal or more than Load Current
2 Load Current
Specify this value to configure the unit in CD Automation
3 Load Voltage
Specify this value to configure the unit in CD Automation
4 Max Voltage of CD3000E
480V 600V
The Max Voltage must be equal or more than Load Voltage
5 Load Connection
3S Star 3D Delta
4S Star + neutral 6D Open Delta
6 Voltage supply for the Electronic boards
110V From 100 to 130Vac 230V From 210 to 265Vac
7 Load Type
RES Resistive IRSW Infrared short wave form
TRA Transformer IRW Infrared medium and long
CR Cold resistance
If the load is transformer that supply a normal resistive load write TRA+RES
8 Firing Type
SC Single Cycle DT Delay Triggering
PA Phase Angle BF___
Burst Firing
S+PA Soft Start + Phase Angle S+BF___
Soft Start + Burst Firing
 Specify the number of firing cycles at 50% of the input signal (from 1 to 255)
9 Feed-Back
V or V2 Voltage W Power
I or I2 Current EX External (0÷10Vdc)
10
Input
0÷10V 0÷10Vdc POT Potentiometer 10KΩ
4÷20mA
4÷20mA Comm RS485
Specify if you use the second analogical input, example: 0÷10V + 4÷20mA
11
External Current Profiler or External Feed-Back
0÷10V 0÷10Vdc POT Potentiometer 10KΩ
Comm RS485
If you don't use the External Current Profiler or External Feed-Back, write: NONE
12
Retransmission
010 0÷10Vdc 020 0÷20mA 420 4÷20mA
13
Option
CD-KP External Keypad NO-HB Without Heater Break alarm
FUMS Fuse Microswitch UL UL Certification
