CD Automation srl CD3000E-3PH from 25A to 500A User’s Manual
25
9 Led status and Alarms
9.1 LED Status Table
On the Electronic board there are LED that indicates the state of the Electronic cards:
LED
For All size
STATUS DESCRIPTION
AUX
The power supply is not connected or fault on the electronic board
Fault on the electronic board
Electronic board is OK
All ON
No alarm
In Alarm
Critical Alarm
SC
SCR OK
SCR short circuit
HB
Laod OK
Load Fault
Current limit active
= OFF
= ON
= Lampeggiante
