CD Automation srl CD3000E-3PH from 25A to 500A User’s Manual
16
6.3 Removing the cover
Size S09
Remove the screw, if present Open the unit
Screw
Open
Size S11
Remove the screw, if present Remove the plastic cover Open the unit
Screw
Screw
Open
Size S13/S14
Remove the screw Remove the plastic cover Open the unit
Screw
Screw
Screw
Screw
Open
