CD Automation srl CD3000E-3PH from 25A to 500A User’s Manual
18
7.1.2 Power cable dimensions (suggested)
Current
Power Supply Cable Load Cable (Output) Earth
mm² AWG mm² AWG mm² AWG
25A (S09) 10 8 10 8 4 12
35A (S09) 10 8 10 8 6 10
45A (S09) 10 8 10 8 6 10
75A (S09) 25 4 25 4 10 8
100A (S11) 35 3 35 3 16 6
125A (S11) 50 1 50 1 16 6
150A (S11) 70 1/0 70 1/0 16 6
225A (S13) 120 4/0 120 4/0 25 4
300A (S14) 2 x 70 2 x 1/0 2 x 70 2 x 1/0 50 1
350A (S14) 2 x 95 2 x 3/0 2 x 95 2 x 3/0 50 1
400A (S14) 2 x 95 2 x 3/0 2 x 95 2 x 3/0 50 1
450A (S14) Bus Bar 30 x 6 mm Bus Bar 30 x 6 mm 70 1/0
500A (S14) Bus Bar 60 x 4 mm Bus Bar 60 x 4 mm 70 1/0
600A (S14) Bus Bar 60 x 4 mm Bus Bar 60 x 4 mm 70 1/0
7.1.3 Cable dimensions of the Command Terminals
Maximum connection capacity for all size: 1.5 mm2 (14 AWG)
