CD Automation srl CD3000E-3PH from 25A to 500A User’s Manual
33
11.2.2 Suggested recipe for Burst Firing
The firing type has already configured in line with customer requirements that are defined in the Order
Code. The Order Code is written on the identification label.
However, if you wish to change the firing type you can use the software configurator or the Control Panel
(see par. 10).
Caution: this procedure must be performed only by qualified persons.
OPERATOR MENU
Parameter
Value Description UM Mode
0 Setpoint selection Analog/Digital R/W
P004 (H04)
Digital Setpoint value % R/W
P019 (H13)
100 Maximum Output % R/W
P024 (H18)
0 Setpoint Ramp Up Sec R/W
P025 (H19)
0 Setpoint Ramp Down Sec R/W
P116 (H74)
V Load Operative load voltage V R/W
P119 (H77)
I Load Load nominal current A R/W
SETUP MENU
Parameter
Value Description UM Mode
0 Firing Type R/W
P066 (H42)
20 HB sensitivity % R/W
P070 (H46)
1 Feed back selection R/W
P083 (H53)
8 Burst Firing Cycles (Not used in Phase Angle) Cycles
Ramp Cycles of Burst (Not used in Phase Angle) Cycles
0 Delay triggering ° R/W
P090 (H5A)
1 Limit current Analog/Digital R/W
P091 (H5B)
0÷100,0 Digital Limit current value % R/W
P098 (H62)
0÷3
Define the load type connection:
0=star
1=star+N
2=delta
3=open delta
R/W
= modification is not necessary
= modification is necessary
If the current limit is not used set this value to 100,0%.
² If don't use the ramp soft start (S+BF) set this value to 0.
