Tachograph programmer CD400 - User manual – V2.00 r07 (9/01/2014) index
3.2. Menu trees
The functions available in the main menu depend on tachograph model detected (or selected manually).
The tachograph model appears on the top line.
3.2.1. KTCO 13xx/1318
KTCO 13xx/1318
1.Measure W
1.Manual
2.Photo sensor
2.Measure K
3.Speed test
1.Manual
2.Automatic
4.Odometer test
5.Clock test
6.Select Tacho.
7.Product info.
8.Language.
3.2.2. MTCO 1324/1390
MTCO 1324/1390
1.Measure W
1.Manual
2.Photo sensor
2.Parameters
1.K Factor
2.Odometer
3.Instal. Date
4.Calibr. Date
5.Time & Date
6.O/P shaft
7.Service delay
8.CAN priority
9.Binary code
10.Product Code
11.VIN
12.N-RPM Factor
13.L-Tyre
14.Serial number
15.Maximum speed (1390 only)
3.Speed test
1.Manual
2.Automatic
4.Odometer test
5.Erase DTCS
6.Sensor pairing
7.Clock test
8.Select Tacho.
9.Product info.
10.Language.
