CTV900A
2-Door Controller
INSTALLATION MANUAL
INSTALLING THE BOX LOCK
Installing the box lock allows to secure the box from non
authorized access. If needed install the box lock as shown
in the following picture (inside view of the door).
1. Remove the box door knock-out.
2. Insert the lock in the hole.
3. Slide the “U” metal part into the lock
groove as shown in the following
picture to secure the lock in place.
Alternatively or complementary to the box lock,
the box may be secured by xing the cover to
its base using screws.
However this should be done only once the
installation of the full 2-Door Controller
system is completed.
1. Use the 4 screws supplied to secure
the box cover to its base as shown
in the following picture.
