CTV900A
2-Door Controller
INSTALLATION MANUAL
3] PACKAGE CONTENTS
This chapter details how to install and setup the CENTAUR 2-Door Controller.
CONTENT OF THE 2-DOOR CONTROLLER
The 2-Door Controller contains:
• One 2-Door Controller module in its cabinet with connection diagram label
• Metal Box kit:
• Installation kit:
If any item is missing, please notify your distributor immediately.
Wall Switch
and a white
wire (115mm)
with a log at
each end
Bolts and Nuts
Wall Switch
Spacer
Door Switch
and 2 white
wire (350mm)
with a log at
one end
Door Switch
Support
Metal box
screw
Metal box
lock and key
Metal Box Kit
11 2 each2 each 11 11 11 44 11
Paire of Wire,
Red and black,
for backup
battery
(400mm)
Backup battery
jumper
1K Resistor 2.2K Resistor
Diode 1N4007
for the door
strikes or
locks
Fastener
(PCB Holder)
Installation
Kit
1 pair1 pair 11 1616 88 22 77
