6
cdvigroup.com
CTV900A
2-Door Controller
INSTALLATION MANUAL
Communication
NETWORK and E-BUS RS485 @ 9.6k or 19,2k Baud (daisy chain topologies) up to 4000ft (1220 meters)
Power Supply
AC Power 24Vac, 75VA (UL/ULC: CDVI150 or CDVI200 recommended, Europe: TR2475 recommended)
Frequency 50Hz/60Hz
Do Not Connect to a Receptacle Controlled by a Switch.
Other 24Vac, 75VA 50/60Hz UL/ULC certied transformer can be use.
On-Board Protection
24Vdc 2.5A Fuseless
12Vdc 1A Fuseless
5Vdc 180mA Fuseless
AC Protection 5A Fuse
Battery 7A Fuse, Against reversal
Power output specications
Battery Backup
Battery Capacity
Two 12Vdc 7Ah rechargeable acid/lead or gel cell backup battery (UL/ULC: YUASA #NP7-12
recommended, Europe: CDVI B7AH recommended). Ensure proper polarity.
Charging Voltage 27.6V
Low Battery @ 21.6Vdc
Low Battery Restore @ 24.1Vdc
Low Battery Cut-O @ 18.5Vdc
Power Outputs
Lock Output 1
Maximum Current 800mA
Lock Output 2
Reader 1
5V= Maximum Current 180mA
12V= Maximum Current 1000mA
24V= Maximum Current 1300mA
Reader 2
Zone Inputs
Auxiliary
Outputs
LK1, LK2 2 Form C Dry Contact 5A/30Vdc N.C/N.O. (Expandle to 16 using CAA460A module)
OUT1,2, 3, 4, 5 and 6 6 open collector 25mA @ 12Vdc (Sink to ground)
