CTV900A
2-Door Controller
INSTALLATION MANUAL
DIP SWITCHES
1 2 4 8 16 32
1 OFF OFF OFF OFF OFF OFF
2 ON OFF OFF OFF OFF OFF
3 OFF ON OFF OFF OFF OFF
4 ON ON OFF OFF OFF OFF
5 OFF OFF ON OFF OFF OFF
6 ON OFF ON OFF OFF OFF
7 OFF ON ON OFF OFF OFF
8 ON ON ON OFF OFF OFF
9 OFF OFF OFF ON OFF OFF
10 ON OFF OFF ON OFF OFF
11 OFF ON OFF ON OFF OFF
12 ON ON OFF ON OFF OFF
13 OFF OFF ON ON OFF OFF
14 ON OFF ON ON OFF OFF
15 OFF ON ON ON OFF OFF
16 ON ON ON ON OFF OFF
17 OFF OFF OFF OFF ON OFF
18 ON OFF OFF OFF ON OFF
19 OFF ON OFF OFF ON OFF
20 ON ON OFF OFF ON OFF
21 OFF OFF ON OFF ON OFF
22 ON OFF ON OFF ON OFF
23 OFF ON ON OFF ON OFF
24 ON ON ON OFF ON OFF
25 OFF OFF OFF ON ON OFF
26 ON OFF OFF ON ON OFF
27 OFF ON OFF ON ON OFF
28 ON ON OFF ON ON OFF
29 OFF OFF ON ON ON OFF
30 ON OFF ON ON ON OFF
31 OFF ON ON ON ON OFF
32 ON ON ON ON ON OFF
Controller Address
DIP SWITCHES
1 2 4 8 16 32
33 OFF OFF OFF OFF OFF ON
34 ON OFF OFF OFF OFF ON
35 OFF ON OFF OFF OFF ON
36 ON ON OFF OFF OFF ON
37 OFF OFF ON OFF OFF ON
38 ON OFF ON OFF OFF ON
39 OFF ON ON OFF OFF ON
40 ON ON ON OFF OFF ON
41 OFF OFF OFF ON OFF ON
42 ON OFF OFF ON OFF ON
43 OFF ON OFF ON OFF ON
44 ON ON OFF ON OFF ON
45 OFF OFF ON ON OFF ON
46 ON OFF ON ON OFF ON
47 OFF ON ON ON OFF ON
48 ON ON ON ON OFF ON
49 OFF OFF OFF OFF ON ON
50 ON OFF OFF OFF ON ON
51 OFF ON OFF OFF ON ON
52 ON ON OFF OFF ON ON
53 OFF OFF ON OFF ON ON
54 ON OFF ON OFF ON ON
55 OFF ON ON OFF ON ON
56 ON ON ON OFF ON ON
57 OFF OFF OFF ON ON ON
58 ON OFF OFF ON ON ON
59 OFF ON OFF ON ON ON
60 ON ON OFF ON ON ON
61 OFF OFF ON ON ON ON
62 ON OFF ON ON ON ON
63 OFF ON ON ON ON ON
64 ON ON ON ON ON ON
Controller Address
Assigning Controller Addresses Via Dip Switches
