TECHNICAL SPECIFICATIONS TABLE
MIG MMA
Mains voltage U1 3x400 V 3x400 V
Tolerance U1 +15% -20% +15% -20%
Mains frequency 50/60 Hz 50/60Hz
Delayed fuse 25A 25A
Power consumed 17.3 kVA 100% 17.3K VA 10 0%
Mains connection Zmax 0.026Ω 0.026Ω
Cos Φ
0.99 0.99
Welding current range 10 – 400A 10 – 380A
X Duty cycle according to standard IEC 60974-1 400A 100% 380A 100%
Open-circuit voltage U0 57V 57V
Maximum welding gas pressure 6bar / 87psi 6bar / 87psi
Maximum wire spool size Ø300mm/15Kg -
Usable electrodes - Ø1.5 – 6.0mm
Performance ɳ ˃85% ˃85%
Consumption in stand-by
˂50W ˂50W
EMC emissions class A A
Overvoltage class III III
Degree of pollution according to IEC 60664 3 3
Certications S, CE S, CE
Degree of protection IP23S IP23S
Weight 111Kg
Dimensions (WxDxH) 527x1078x1398
2�2 Protections
2�2�1 Lock protection
If the welder malfunctions, a WARNING message may appear on display1. This identies the type of defect. If the
message is still present after turning the machine off and on, contact the assistance service.
2�2�2 Thermal protection
This device is protected by a thermostat which prevents the machine from operating if the allowable temperatures are
exceeded. Under these conditions, the fan continues to operate and display 1 shows the ashing WARNING CODE tH.
3 INSTALLATION AND START UP
The system must be installed by qualied personnel. Carefully read the “Staff obligations and qualications” section
in General Warnings code 3301151.
During transport of the device, ensure that applicable national and regional accident prevention guidelines and
regulations are observed. This applies in particular to guidelines concerning transport and shipping risks.
Carefully read the “Lifting and transporting” section in General Warnings code 3301151
DANGER
Tipping a device over may endanger life! Position the device stably on a solid, at base.
A maximum angle of inclination of 10° is allowed. Do not lift or transport live devices. The machine should not be
positioned on sloping planes, to prevent tilting or any uncontrolled movement.
